Malvern Turbine and Pump Unit for Energy Transfer

This turbine/pump unit is part of the Malvern energy transfer apparatus system. It features a rotor with eight bucket blades housed in a block turbine chamber measuring 50 x 50 x 25mm, with a clear Perspex front for observation. Two inlet tubules (one each for turbine and pump operation) and one outlet are provided. The shaft carries a 15mm diameter pulley. The overall unit measures 15 x 10 cm. The unit can function as a water turbine to drive a generator producing electricity, or as a pump driven by a motor to raise a head of water and produce potential energy.
